Dual Channel HX711 24Bit Load Cell Interface

SKU: VBD2384
R23.50
VAT Inclusive
Delivery: 2-5 working days
Dual Channel HX711 24Bit Load Cell Interface board
Quantity
Wishlist
Compare

Spend R2,000.00 more and get Free Shipping!
  • Two selectable differential input channels
  • On-chip active low noise PGA with selectable gain of 32, 64 and 128
  • On-chip power supply regulator for load-cell and ADC analog power supply
  • On-chip oscillator requiring no external component with optional external crystal
  • On-chip power-on-reset
  • Simple digital control and serial interface: pin-driven controls, no programming needed
  • Selectable 10SPS or 80SPS output data rate
  • Simultaneous 50 and 60Hz supply rejection
  • Current consumption including on-chip analog power supply regulator: normal operation < 1.5mA, power down < 1uA
  • Operation supply voltage range: 2.6 ~ 5.5V
  • Operating Temperature Range:-20 degree ~ +85 degree
VBD2384
4 Items
